基于分形理论无腹筋混凝土梁的受剪性能

于江 吕旭滨 秦拥军

于江, 吕旭滨, 秦拥军. 基于分形理论无腹筋混凝土梁的受剪性能[J]. 工程科学学报. doi: 10.13374/j.issn2095-9389.2020.03.19.003
引用本文: 于江, 吕旭滨, 秦拥军. 基于分形理论无腹筋混凝土梁的受剪性能[J]. 工程科学学报. doi: 10.13374/j.issn2095-9389.2020.03.19.003
YU Jiang, LÜ Xu-bin, QIN Yong-jun. Experimental study on concrete beams without web reinforcement based on fractal theory[J]. Chinese Journal of Engineering. doi: 10.13374/j.issn2095-9389.2020.03.19.003
Citation: YU Jiang, LÜ Xu-bin, QIN Yong-jun. Experimental study on concrete beams without web reinforcement based on fractal theory[J]. Chinese Journal of Engineering. doi: 10.13374/j.issn2095-9389.2020.03.19.003

基于分形理论无腹筋混凝土梁的受剪性能

doi: 10.13374/j.issn2095-9389.2020.03.19.003
基金项目: 国家自然科学基金资助项目(51668060)
详细信息
    通讯作者:

    E-mail:1332506524@qq.com

  • 中图分类号: TU375.1

Experimental study on concrete beams without web reinforcement based on fractal theory

More Information
  • 摘要: 基于裂缝的发展及分布形态,探究无腹筋混凝土梁在不同剪跨比和纵筋配筋率作用下的剪切性能,采用剪跨比分别为1.5、2、2.5和纵筋配筋率分别为1.28%、1.62%、1.99%的9组无腹筋混凝土梁进行四点加载受剪试验,通过应用分形几何理论对试验梁表面的裂缝进行分析,使用盒计数法计算得到分级荷载及极限荷载作用下梁表面裂缝的分形维数,探讨了梁表面分形维数与极限荷载、分级荷载及跨中挠度之间的关系。结果表明:剪跨比与极限荷载及开裂荷载成反比,而纵筋配筋率与极限荷载成正比,但其对于开裂荷载的影响较小。无腹筋混凝土梁不论在分级加载作用下还是极限荷载作用下都具备明显的分形特征,在分级荷载作用下的分形维数在0.964~1.449,在极限荷载作用下的分形维数在1.33附近。分级荷载、跨中挠度与分形维数之间呈现较好的对数关系,分级荷载与分形维数的变化曲线受剪跨比及梁纵筋配筋率的影响具有一定的规律性,而跨中挠度受剪跨比的影响较小,在纵筋配筋率作用下,其曲线的曲率呈现出先增大后减小的趋势,但极限荷载与分形维数之间的关系具有一定的差异性,极限荷载会随着剪跨比的增大呈现出先增大后减小的趋势,随着纵筋配筋率的增大呈现出的差异性较大。



  • 图  1  无腹筋梁尺寸及配筋图(单位: mm)

    Figure  1.  Dimensions and reinforcement drawing of girder without rib (Unit: mm)

    图  2  加载装置布置图。(a)λ = 1.5;(b)λ = 2;(c)λ = 2.5;(d)现场布置图

    Figure  2.  Load device layout: (a) λ = 1.5; (b) λ = 2; (c) λ = 2.5; (d) site layout

    图  3  试验梁裂缝分布图。(a)WL-1;(b)WL-2;(c)WL-3;(d)WL-4;(e)WL-5;(f)WL-6;(g)WL-7;(h)WL-8;(i)WL-9

    Figure  3.  Crack distribution of test beam: (a) WL-1; (b) WL-2; (c) WL-3; (d) WL-4; (e) WL-5; (f) WL-6; (g) WL-7; (h) WL-8; (i) WL-9

    图  4  相同剪跨比、不同纵筋配筋率作用下的荷载与挠度间关系。(a) λ = 1.5;(b)λ = 2;(c)λ = 2.5

    Figure  4.  Relationship between load and deflection under the same shear-span ratio and different longitudinal reinforcement ratios: (a) λ = 1.5; (b) λ = 2; (c) λ = 2.5

    图  5  相同纵筋配筋率、不同剪跨比作用下荷载与挠度间的关系。(a)ρ = 1.28%;(b)ρ = 1.62%;(c)ρ = 1.99%

    Figure  5.  Relationship between load and deflection under the same longitudinal reinforcement ratio and different shear span ratios: (a) ρ = 1.28%; (b) ρ = 1.62%; (c) ρ = 1.99%

    图  6  开裂荷载与极限荷载对比图

    Figure  6.  Comparison of cracking load and ultimate load

    图  7  不同等级荷载下梁表面的lnN(L)–ln(1/L)图。(a)WL-1;(b)WL-2;(c)WL-3;(d)WL-4;(e)WL-5;(f)WL-6;(g)WL-7;(h)WL-8;(i)WL-9

    Figure  7.  lnN(L)–ln(1/L) diagram of beam surface under different grades of load: (a) WL-1; (b) WL-2; (c) WL-3; (d) WL-4; (e) WL-5; (f) WL-6; (g) WL-7; (h) WL-8; (i) WL-9

    图  8  极限荷载下梁表面的lnN(L)–ln(1/L)图

    Figure  8.  lnN(L)–ln(1/L) diagram of the beam surface under ultimate load

    图  9  极限荷载作用下梁的分形维数

    Figure  9.  Fractal dimension of the beam under ultimate load

    图  10  相同剪跨比、不同纵筋配筋率作用下的极限荷载与分形维数间的关系。(a)λ = 1.5;(b)λ = 2;(c)λ = 2.5

    Figure  10.  Relationship between ultimate load and fractal dimension under the same shear span ratio and different longitudinal reinforcement ratios: (a) λ = 1.5, (b) λ = 2, (c) λ = 2.5

    图  11  相同纵筋配筋率、不同剪跨比作用下的极限荷载与分形维数间的关系。(a)ρ = 1.28%;(b)ρ = 1.62%;(c)ρ = 1.99%

    Figure  11.  Relationship between ultimate load and fractal dimension under the same longitudinal reinforcement ratio and different shear span ratios: (a) ρ = 1.28%; (b) ρ = 1.62%; (c) ρ = 1.99%

    图  12  相同剪跨比、不同纵筋配筋率作用下的分级荷载与分形维数间关系。(a)λ = 1.5;(b)λ = 2;(c)λ = 2.5

    Figure  12.  Relationship between the graded load and the fractal dimension under the same shear span ratio and different longitudinal reinforcement ratios: (a) λ = 1.5; (b) λ = 2; (c) λ = 2.5

    图  13  相同纵筋配筋率、不同剪跨比作用下的分级荷载与分形维数间关系。(a)ρ = 1.28%;(b)ρ = 1.62%;(c)ρ = 1.99%

    Figure  13.  Relationship between the graded load and the fractal dimension under the same longitudinal reinforcement ratio and different shear span ratios: (a) ρ = 1.28%; (b) ρ = 1.62%; (c) ρ = 1.99%

    图  14  相同剪跨比、不同纵筋配筋率作用下的跨中挠度与分形维数间的关系。(a)λ = 1.5;(b)λ = 2;(c)λ = 2.5

    Figure  14.  Relationship between mid-span deflection and fractal dimension under the same shear-span ratio and different longitudinal reinforcement ratios: (a) λ = 1.5; (b) λ = 2; (c) λ = 2.5

    图  15  相同纵筋配筋率、不同剪跨比作用下的跨中挠度与分形维数间关系。(a)ρ = 1.28%;(b)ρ = 1.62%;(c)ρ = 1.99%

    Figure  15.  Relationship between mid-span deflection and fractal dimension under the same longitudinal reinforcement ratio and different shear-span ratios: (a) ρ = 1.28%; (b) ρ = 1.62%; (c) ρ = 1.99%

    表  1  水泥的化学成分(质量分数)

    Table  1.   Chemical composition of cement %

    SiO2Al2O3Fe2O3CaOMgOSO3K2ONa2OLi2O
    21.225.053.2660.240.972.670.500.73
    下载: 导出CSV

    表  2  粗骨料的实验性能

    Table  2.   Properties of coarse aggregate

    Micron content/%Water absorption rate/%Needle-like content/%Ruggedness/
    %
    Apparent density/(kg·m–3)
    0.30.5512640
    下载: 导出CSV

    表  3  试件参数信息

    Table  3.   Parameter information of test pieces

    NumberingSize/mmCompressive strength/MPaReinforcement diameter/mmLongitudinal strengthShear span ratioReinforcement ratio/%
    WL-11800×150×25041.03116HRB4001.51.28
    WL-21800×150×25044.10316HRB40021.28
    WL-31800×150×25042.77216HRB4002.51.28
    WL-41800×150×25038.46718HRB4001.51.62
    WL-51800×150×25037.00318HRB40021.62
    WL-61800×150×25036.83218HRB4002.51.62
    WL-71800×150×25038.60720HRB4001.51.99
    WL-81800×150×25038.47120HRB40021.99
    WL-91800×150×25046.21920HRB4002.51.99
    下载: 导出CSV

    表  4  不同荷载作用下梁表面分形维数

    Table  4.   Fractal dimension of beam surface under different loads

    Load/kNFractal dimension
    WL-1WL-2WL-3WL-4WL-5WL-6WL-7WL-8WL-9
    200.9640.951
    401.0181.0441.0400.9911.0421.0820.9911.0580.955
    601.0591.11.2751.0441.0751.2210.9991.0721.122
    801.0931.211.3361.1331.2151.3301.0541.1701.161
    1001.1641.321.2031.2831.4491.1571.2481.321
    1201.2671.2081.3401.1881.295
    1401.3041.2181.3571.1931.354
    1601.3021.2761.207
    1801.3351.3561.255
    1901.333
    下载: 导出CSV

    表  5  分级荷载与分形维数关系的km

    Table  5.   k, m values of the relationship between the graded load and the fractal dimension

    ParametersWL-1WL-2WL-3WL-4WL-5WL-6WL-7WL-8WL-9
    k0.1560.1490.1130.1500.1410.0820.1400.1200.148
    m8.984–6.256.258.827–1.48127.0378.6934.824–20.653
    R20.9260.8960.8920.9430.9420.8900.8980.9170.921
    下载: 导出CSV

    表  6  跨中挠度与分形维数关系的nv

    Table  6.   n, v values of the relationship between the mid-span deflection and the fractal dimension

    ParametersWL-1WL-2WL-3WL-4WL-5WL-6WL-7WL-8WL-9
    n0.1290.1080.1160.1230.0970.0560.1260.1020.093
    v83.04782.72773.28166.04968.4577551.30752.61348.898
    R20.9370.9390.9660.9500.9370.9220.9280.9040.966
    下载: 导出CSV
  • [1] Du X L, Jie P L, Jin L. Dynamic flexural-tensile failure mode analysis of concrete beam with initial defect. Eng Mech, 2015, 32(2): 74

    杜修力, 揭鹏力, 金浏. 考虑初始缺陷影响的混凝土梁动态弯拉破坏模式分析. 工程力学, 2015, 32(2):74
    [2] Sun Y B, Yu G M, Zhang Y, et al. Fractal study on crack growth path of reinforced concrete beams fracture. Eng Constr, 2016, 48(7): 6

    孙叶冰, 于广明, 张洋, 等. 钢筋混凝土梁断裂裂纹扩展路径的分形研究. 工程建设, 2016, 48(7):6
    [3] Tang C A, Zhu W C. A Numerical Experiment of Concrete Damage and Fracture. Beijing: Science Press, 2003

    唐春安, 朱万成. 混凝土损伤与断裂: 数值试验. 北京: 科学出版社, 2003
    [4] Mandelbort B B, Wheeler J A. The fractal geometry of nature. Am J Phys, 1983, 51(3): 286 doi: 10.1119/1.13295
    [5] Ma X, Xie X P, Ye X W, et al. Fractal characteristics of pore structure of calcium-based geopolymer based on nitrogen adsorption. Mater Rev, 2019, 33(12): 1989 doi: 10.11896/cldb.18030014

    马骁, 谢雪鹏, 叶雄伟, 等. 基于氮气吸附法的钙基地聚合物孔隙结构分形特征. 材料导报, 2019, 33(12):1989 doi: 10.11896/cldb.18030014
    [6] Li G Q, Deng X J. Fractal effect of graded aggregate. Concrete, 1995(1): 3

    李国强, 邓学钧. 级配骨料的分形效应. 混凝土, 1995(1):3
    [7] Zhou J H, Kang T B, Wang F C. Pore structure and carbonation fractal characteristics of waste fiber recycled concrete. Bull Chin Ceram Soc, 2017, 36(5): 1686

    周静海, 康天蓓, 王凤池. 废弃纤维再生混凝土孔结构及碳化性能分形特征研究. 硅酸盐通报, 2017, 36(5):1686
    [8] Tian W, Dang F N, Chen H Q. Fractal analysis on meso-fracture of concrete based on the technique of CT image processing. J Basic Sci Eng, 2012, 20(3): 424 doi: 10.3969/j.issn.1005-0930.2012.03.009

    田威, 党发宁, 陈厚群. 基于CT图像处理技术的混凝土细观破裂分形分析. 应用基础与工程科学学报, 2012, 20(3):424 doi: 10.3969/j.issn.1005-0930.2012.03.009
    [9] Jiao C J, Li X B, Cheng C M, et al. Dynamic damage constitutive relationship of high strength concrete based on fractal theory. Explos Shock Waves, 2018, 38(4): 925

    焦楚杰, 李习波, 程从密, 等. 基于分形理论的高强混凝土动态损伤本构关系. 爆炸与冲击, 2018, 38(4):925
    [10] Zhang W S, Zhang J B, Li J Y, et al. Research of pore area fractal characteristic of concrete and its test method. J Build Mater, 2012, 15(3): 312 doi: 10.3969/j.issn.1007-9629.2012.03.004

    张文生, 张建波, 李建勇, 等. 混凝土孔隙面分形特征与测试方法研究. 建筑材料学报, 2012, 15(3):312 doi: 10.3969/j.issn.1007-9629.2012.03.004
    [11] Dong Y L, Xie H P, Zhao P. Study on b value and fractal dimension Df of concrete under complete process compression. J Exp Mech, 1996, 11(3): 272

    董毓利, 谢和平, 赵鹏. 砼受压全过程声发射b值与分形维数的研究. 实验力学, 1996, 11(3):272
    [12] Wu K R, Yan A, Yao W, et al. Effect of metallic aggregate on strength and fracture properties of HPC. Cem Concr Res, 2001, 31(1): 113 doi: 10.1016/S0008-8846(00)00431-2
    [13] Yan A, Wu K R, Zhang D, et al. Effect of fracture path on the fracture energy of high-strength concrete. Cem Concr Res, 2001, 31(11): 1601 doi: 10.1016/S0008-8846(01)00610-X
    [14] Xu Z B, Xie H P. The relation between the fractal distribution and the damage evolvement of fracture structure. J Wuhan Univ Technol, 2004, 26(10): 28 doi: 10.3321/j.issn:1671-4431.2004.10.009

    徐志斌, 谢和平. 断裂构造的分形分布与其损伤演化的关系. 武汉理工大学学报, 2004, 26(10):28 doi: 10.3321/j.issn:1671-4431.2004.10.009
    [15] Carpinteri A. Fractal nature of material microstructure and size effects on apparent mechanical properties. Mech Mater, 1994, 18(2): 89 doi: 10.1016/0167-6636(94)00008-5
    [16] Carpinteri A, Chiaia B. Crack-resistance behavior as a consequence of sell-similar fracture topologies. Int J Fract, 1996, 76(4): 327 doi: 10.1007/BF00039781
    [17] Qin Z P, Tian Y, Li G, et al. Study on fractal features of flexural performance of reinforced concrete beams strengthened with BFRP sheets. J Basic Sci Eng, 2018, 26(5): 973

    秦子鹏, 田艳, 李刚, 等. BFRP布加固钢筋混凝土梁抗弯性能的分形特征研究. 应用基础与工程科学学报, 2018, 26(5):973
    [18] Zhou R Z. Fractal mechanics significance of stress field singularity at crack tip for concrete structures. J Dalian Univ Technol, 1997, 37(Suppl 1): 67

    周瑞忠. 混凝土结构裂纹尖端应力场奇异性的分形力学意义. 大连理工大学学报, 1997, 37(增刊 1):67
    [19] Luan H Y, Fan Y F, Wang D W, et al. Study on the flexural behavior of the CFRP-reinforced concrete beam with fractal theory. Eng Mech, 2015, 32(4): 160

    栾海洋, 范颖芳, 王大为, 等. 基于分形理论的CFRP布增强混凝土梁抗弯性能研究. 工程力学, 2015, 32(4):160
    [20] Jia N, Guo J X, Wen W Q, et al. Three-dimensional characterization of wood surface roughness with improved differential box-counting. J Northeast Forest Univ, 2019, 47(9): 76 doi: 10.3969/j.issn.1000-5382.2019.09.014

    贾娜, 郭佳欣, 温潍齐, 等. 应用改进差分盒维数法对木材表面粗糙度的三维表征. 东北林业大学学报, 2019, 47(9):76 doi: 10.3969/j.issn.1000-5382.2019.09.014
    [21] Chen S J, Zhang X N. Fractal characteristics of asphalt mixtures based on digital image processing technique. J Build Mater, 2013, 16(3): 451 doi: 10.3969/j.issn.1007-9629.2013.03.013

    陈尚江, 张肖宁. 基于数字图像处理技术的沥青混合料分形特性. 建筑材料学报, 2013, 16(3):451 doi: 10.3969/j.issn.1007-9629.2013.03.013
    [22] Cao M S, Ren Q W, Zhai A L, et al. Experimental study on fractal characterization in damages of concrete structures. Rock Soil Mech, 2005, 26(10): 1570 doi: 10.3969/j.issn.1000-7598.2005.10.009

    曹茂森, 任青文, 翟爱良, 等. 混凝土结构损伤的分形特征实验分析. 岩土力学, 2005, 26(10):1570 doi: 10.3969/j.issn.1000-7598.2005.10.009
    [23] Yang S, Shao L T, Guo X X, et al. Skeleton and fractal law based image recognition algorithm for concrete crack. Chin J Sci Instrum, 2012, 33(8): 1850 doi: 10.3969/j.issn.0254-3087.2012.08.025

    杨松, 邵龙潭, 郭晓霞, 等. 基于骨架和分形的混凝土裂缝图像识别算法. 仪器仪表学报, 2012, 33(8):1850 doi: 10.3969/j.issn.0254-3087.2012.08.025
    [24] Liu X Y, Li W W, Liang Z P. Application to fractal theory in study on the fracture surfaces of concrete. J China Three Gorges Univ Nat Sci, 2003, 25(6): 495

    刘小艳, 李文伟, 梁正平. 分形理论在混凝土断裂面研究中的应用. 三峡大学学报(自然科学版), 2003, 25(6):495
    [25] Wang J A, Xie H P, Tian X Y, et al. Direct fractal measurement of fracture surfaces. J Univ Sci Technol Beijing, 1999, 21(1): 6 doi: 10.3321/j.issn:1001-053X.1999.01.002

    王金安, 谢和平, 田晓燕, 等. 一种新的断裂表面分形测量方法. 北京科技大学学报, 1999, 21(1):6 doi: 10.3321/j.issn:1001-053X.1999.01.002
    [26] Yan A, Wu K R, Zhang D, et al. Study on the multi-fractal characterization of fracture surface of concrete materials. J Build Mater, 2002, 5(1): 46 doi: 10.3969/j.issn.1007-9629.2002.01.009

    严安, 吴科如, 张东, 等. 混凝土材料断裂表面的多重分形特征研究. 建筑材料学报, 2002, 5(1):46 doi: 10.3969/j.issn.1007-9629.2002.01.009
    [27] Zhang Q L, Hou G T, Pan W Q, et al. Fractal study on structural fracture. J Basic Sci Eng, 2011, 19(6): 853 doi: 10.3969/j.issn.1005-0930.2011.06.001

    张庆莲, 侯贵廷, 潘文庆, 等. 构造裂缝的分形研究. 应用基础与工程科学学报, 2011, 19(6):853 doi: 10.3969/j.issn.1005-0930.2011.06.001
