楚志兵, 魏栋, 杨彦龙, 黄庆学, 胡正寰. 不同送进量对皮尔格轧制成形的影响及验证[J]. 工程科学学报, 2017, 39(5): 747-755. DOI: 10.13374/j.issn2095-9389.2017.05.013
引用本文: 楚志兵, 魏栋, 杨彦龙, 黄庆学, 胡正寰. 不同送进量对皮尔格轧制成形的影响及验证[J]. 工程科学学报, 2017, 39(5): 747-755. DOI: 10.13374/j.issn2095-9389.2017.05.013
CHU Zhi-bing, WEI Dong, YANG Yan-long, HUANG Qing-xue, HU Zheng-huan. Influence and verification of different feed ranges on cold pilgering[J]. Chinese Journal of Engineering, 2017, 39(5): 747-755. DOI: 10.13374/j.issn2095-9389.2017.05.013
Citation: CHU Zhi-bing, WEI Dong, YANG Yan-long, HUANG Qing-xue, HU Zheng-huan. Influence and verification of different feed ranges on cold pilgering[J]. Chinese Journal of Engineering, 2017, 39(5): 747-755. DOI: 10.13374/j.issn2095-9389.2017.05.013

不同送进量对皮尔格轧制成形的影响及验证

Influence and verification of different feed ranges on cold pilgering

  • 摘要: 皮尔格冷轧无缝钢管过程中为了获得性能较好的成品需要选择合理的送进量数值,本文以冷轧304不锈钢为研究对象,借助有限元模拟软件对不同送进量下的皮尔格冷轧过程进行了完整的仿真,对比分析了送进量对金属流动速度、轧制力、等效应力、残余应力及管材回弹的影响规律.结果表明轧制过程中孔型背脊和与轧辊接触的孔型侧壁处管材金属流动速度随送进量增加而增加,轧制力、等效应力及残余应力均随送进量的增加而增大,并且送进量的增大还会显著增加管材的回弹量.借助试验轧机对不同送进量下皮尔格冷轧管进行轧制试验,对试验得到的管材进行尺寸和残余应力测量,测量结果与有限元仿真结果基本一致,为皮尔格轧制过程不同送进量的选择提供依据.



    Abstract: To achieve better performance in finished cold-pilger rolled stainless steel tubes, it is critical to select an appropriate feed range. In this study, cold-rolling 304 stainless steel tube was used as the research object to simulate the entire cold-pilgering process at different feed ranges. Using finite element software, it was comparatively analyzed that the feed range effects on the metal flow rate, rolling force, equivalent stress, residual stress, and piping spring-back. The results indicate that the metal flow rate increases with an increased feed range in the groove bottom and the contact of the groove flank with the roll. In addition, the rolling force, equivalent stress and residual stress increase with increases in the feed range, increments of which will increase the spring-back of the piping. Rolling tests at different feed ranges were performed with the help of experimental rolling mill and it is found that test results are roughly identical to the simulation results. experimental test results regarding the dimensions and residual stress of the piping provide evidence for optimizing the selection of the feed range in pilger rolling.



/
