摘要: 为改善塑管混凝土结构的界面密闭性能，研究了在塑管−混凝土界面粘贴一种双面压敏胶带——Preprufe胶带的作用。通过界面黏结强度、界面渗水高度和界面透气性实验，测得塑管混凝土结构的界面黏结强度、界面渗水高度、气体压力−时间衰减曲线，推导出界面渗透指数。试验结果表明，界面黏结强度与粘贴胶带的宽度的关系可初步认为符合幂函数分布，压敏性粘合剂胶层与液态混凝土在硬化过程中形成的黏结强度远大于普通黏性层与塑管间的黏结强度。粘贴Preprufe胶带可显著提高塑管−混凝土界面抗渗能力。界面渗透指数随粘贴胶带的宽度增大呈明显的递减趋势，粘贴220 mm宽胶带的塑管混凝土试件界面渗透指数仅为基准塑管混凝土试件的2.86%。Preprufe双面压敏胶带在改善塑管−混凝土界面密闭性能上有良好的表现。在工程应用中可综合考虑所需效果和价格成本来选取粘贴胶带的宽度。Abstract: Concrete structures, such as bridge piers and pile foundations, in tidal/splash zones and soil–air transition zones in saline environments often suffer more severe structural corrosion and reinforcement corrosion than the structures completely in water, soil, or air. The application of plastic-pipe concrete can effectively solve this problem. Plastic-pipe concrete is formed by pouring concrete into a large-diameter plastic pipe with a certain structural size. Plastic pipes can protect the bridge piers and eliminate the water level change area and the soil–air junction area in structural design, to realize the integrated anti-corrosion protection of the bridge piers in the saline environment. The anti-corrosion protection effect of the plastic-pipe–concrete system depends on the impermeability of the plastic pipe–concrete interface. The difference in linear expansion coefficient between the plastic pipe and concrete and the shrinkage of the core concrete will damage the bonding layer between the plastic pipe and concrete, consequently affecting the interface impermeability. To improve the impermeability of the plastic pipe–concrete interface, the effect of a pressure-sensitive adhesive tape (Preprufe double-sided tape) attached to the plastic pipe–concrete interface was studied. Experiments were conducted to determine the interfacial bond strength, interfacial water penetration height, and interfacial air permeability, and the gas pressure–time decay curve was measured, and the interface permeability index was deduced. The experiment results show that the relationship between the interfacial bond strength and the adhesive tape width can be preliminarily considered as a power function distribution. The bond strength formed between the pressure-sensitive adhesive layer and the liquid concrete during the hardening process is much greater than that between the ordinary adhesive tape and the plastic pipe. Pasting the Preprufe tapes can significantly improve the impermeability of the plastic pipe–concrete interface. The interfacial permeability index decreases with the increase in the adhesive tape width, and the interfacial permeability index coefficient of plastic pipe–concrete specimens with 220 mm–wide tape is only 2.86% of that of the specimens without tape. The Preprufe double-sided pressure-sensitive tape has good performance in improving the impermeability of plastic pipe–concrete interfaces. In engineering applications, the adhesive tape width can be selected based on the required effect and cost.
-
图 2 Preprufe胶带的宏观与微观构造图。（a）宏观构造图；（b, c）微观构造图
Figure 2. Macrostructure and microstructure of the Preprufe tape: (a) macrostructure; (b, c) microstructure
图 3 粘贴Preprufe双面胶带的塑管−混凝土试件
Figure 3. Plastic pipe–concrete specimens with the Preprufe double-sided tape
图 6 界面透气性测试系统。（a）示意图；（b）实物图
Figure 6. Interface airtightness test system: (a) diagram; (b) objects
图 7 PRE-0压力−时间衰减曲线及其拟合曲线
Figure 7. Pressure–time decay curve and its fitting curve of PRE-0
图 8 Preprufe胶带宽度与界面黏结强度的关系
Figure 8. Width of the Preprufe double-sided tape vs interface bonding strength
图 9 核心混凝土渗水高度。（a）外表面；（b）内部
Figure 9. Seepage height of central concrete: (a) surface; (b) inner region
图 11 Preprufe胶带宽度与衰减时间Td的关系。（a）常规数值刻度；（b）对数刻度
Figure 11. Width of the Preprufe double-sided tape vs decay time Td: (a) conventional numerical scale; (b) logarithmic scale
图 12 Preprufe胶带宽度与界面渗透指数Ω的关系。（a）常规数值刻度；（b）对数刻度
Figure 12. Width of the Preprufe double-sided tape vs interface permeability index Ω: (a) conventional numerical scale; (b) logarithmic scale
表 1 C40混凝土配合比及基本性能
Table 1. C40 concrete mix ratio and basic performance
Water /(kg·m−3) Cement /(kg·m−3) Fine aggregate /(kg·m−3) Coarse aggregate /(kg·m−3) Slump /cm 28 d compressive strength /MPa 176 352 732 1140 18 52.0
下载: 导出CSV
表 2 粘贴不同宽度Preprufe双面胶带的塑管−混凝土界面密闭性能试验结果
Table 2. Test results of impermeability of plastic pipe−concrete interface with Preprefe tape of different widths
Specimens Bond strength/
kPaInterfacial water penetration height Interfacial airtightness Water penetration height/cm Permeability coefficient/(10−7·cm·s−1) Decay time/s Permeability index, Ω/(10−3·s−1) PRE-0 44.6 13.85 2.38 199 9.43 PRE-55 263 0 — 383 4.41 PRE-110 512 0 — 1248 1.11 PRE-220 1070 0 — 3349 0.27 Note: The decay time refers to the time consumed when the pressure in the gasholder decays from 200 to 30 kPa
下载: 导出CSV
-
[1] Mohammed T U. Hamada H, Yamaji T. Performance of seawater-mixed concrete in the tidal environment. Cem Concr Res, 2004, 34(4): 593 doi: 10.1016/j.cemconres.2003.09.020 [2] 吴金海. 海洋环境下混凝土结构耐久性研究[学位论文]. 杭州: 浙江大学, 2004Wu J H. Study on the Durability of Reinforced Concrete Structure in Marine Environment [Dissertation]. Hangzhou: Zhejiang University, 2004 [3] Elnaggar E M, Elsokkary T M, Shohide M A, et al. Surface protection of concrete by new protective coating. Constr Build Mater, 2019, 220: 245 doi: 10.1016/j.conbuildmat.2019.06.026 [4] Elhalawany N R, Nawwar G A M. Novel polymer/hybrid coatings for concrete protection using poly methyl methacrylate (scrap) as seeded particles. J Elastomers Plast, 2015, 47(4): 370 doi: 10.1177/0095244313514990 [5] Swamy R N, Tanikawa S. Surface Coating for Sustainable Protection and Rehabilitation of Concrete Structures. Tokyo: Kohbunsha, 2012 [6] Larsen K P. Surface-applied corrosion inhibitors extend life of reinforced steel concrete structures. Mater Perform, 2019, 58(3): 12 [7] Lu Y Y, Hu J Y, Li S, et al. Active and passive protection of steel reinforcement in concrete column using carbon fibre reinforced polymer against corrosion. Electrochim Acta, 2018, 278: 124 doi: 10.1016/j.electacta.2018.05.037 [8] 周扬, 陈翠翠, 蔡景顺, 等. 耐蚀钢筋的腐蚀行为及其与阻锈剂的协同防腐作用. 建筑材料学报, 2016, 19(2):379Zhou Y, Chen C C, Cai J S, et al. Corrosion behavior of corrosion resistant reinforcing steels and their synergistic corrosion resistant effect with corrosion inhibitor. J Build Mater, 2016, 19(2): 379 [9] Whitmore D, Miltenberger M. Galvanic cathodic protection of corroded reinforced concrete structures. Mater Perform, 2019, 58(10): 24 [10] 左俊卿, 姚武. CNT-CF 水泥基材料辅助阳极对钢筋混凝土阴极保护影响. 建筑材料学报, 2016, 19(3):424Zuo J Q, Yao W. Effect of CNT-CF cement-based materials auxiliary anode on cathodic protection of reinforced concrete. J Build Mtear, 2016, 19(3): 424 [11] Mangaiyarkarasi G, Muralidharan S. Electrochemical protection of steel in concrete to enhance the service life of concrete structures. Procedia Eng, 2014, 86: 615 doi: 10.1016/j.proeng.2014.11.087 [12] 张彦军, 韩文礼, 张贻刚, 等. 海洋平台桩腿防腐层修复三层包覆防护结构研究与应用. 表面技术, 2016, 45(11):123Zhang Y J, Han W L, Zhang Y G, et al. Research and application of three-layer coating protective structure for offshore platform pile leg. Surf Technol, 2016, 45(11): 123 [13] 胡津津, 石明伟. 海洋平台的腐蚀及防腐技术. 中国海洋平台, 2008, 23(6):39Hu J J, Shi M W. Corrosion and anticorrosion technology in offshore platforms. China Offshore Platform, 2008, 23(6): 39 [14] Strange A E. Corrosion control with induced tension polymer wraps. Materials Performance, 1996, 35(10): 32 [15] GCP Applied Technologies Inc. Below grade waterproofing brings massive transit project back on track [EB/OL]. [2020-04-10]. https://gcpat.com/en/solutions/products/preprufe-membrane-pre-applied-waterproofing-solutions/preprufe-scs-us-version. [16] 丁红梅. 高分子自粘胶膜防水卷材及其预铺施工技术 //中国土木工程学会隧道与地下工程分会防水排水专业委员会第十五届学术交流会论文集. 昆明, 2011: 93Ding H M. Prefabricated polymer self-adhesive waterproofing membrane and its construction technology // Proceedings of the 15th Academic Exchange Meeting of the Waterproofing and Drainage Professional Committee of the Tunnel and Underground Engineering Branch of the China Civil Engineering Society. Kunming, 2011: 93 [17] 刘兵科, 邵翔宇, 吕军斗. 预铺式自粘防水卷材在北京地铁知春路车站的应用// 第二届全国岩土与工程学术大会论文集. 武汉, 2006: 718Liu B K, Shao X Y, Lü J D. Appllication of preprufe waterproof material in Zhichunlu station of Beijing metro // Proceedings of the Second National Geotechnical and Engineering Conference. Wuhan, 2006: 718 [18] Wiercinski R A, Ranganathan A. Waterproofing Membrane: US Patent, US 20120180933.2012-07-19 [19] Sun S M, Li M L, Liu A. A review on mechanical properties of pressure sensitive adhesives. Int J Adhes Adhes, 2013, 41: 98 doi: 10.1016/j.ijadhadh.2012.10.011 [20] 姜宇. 给排水管道施工中新型管材的选用及研究进展. 企业技术开发, 2013, 32(5):45Jiang Y. Study on the selection and research progress of new type pipes in water supply and drainage construction. Technol Dev Enterprise, 2013, 32(5): 45 [21] Ahmed A, Guo S C, Zhang Z H, et al. A review on durability of fiber reinforced polymer (FRP) bars reinforced seawater sea sand concrete. Constr Build Mater, 2020, 256: 119484 doi: 10.1016/j.conbuildmat.2020.119484 [22] Wang J L. Cohesive-bridging zone model of FRP-concrete interface debonding. Eng Fract Mech, 2007, 74(17): 2643 doi: 10.1016/j.engfracmech.2007.02.013 [23] 南京水利科学研究院, 中国水利水电科学研究院. DL/T 5150—2001水工混凝土试验规程. 北京: 中国电力出版社, 2002Nanjing Hydraulic Research Institute, China Institute of Water Resources and Hydropower Research. DL/T 5150—2001 Test Code for Hydraulic Concrete. Beijing: China Electric Power Press, 2002 [24] 刘文波, 嵇艳玲, 沙元福. 抗渗混凝土试验间断的处理. 水利科技与经济, 1999, 5(1):45Liu W B, Ji Y L, Sha Y F. Discontinuous treatment of impervious concrete test. Water Conserv Sci Technol Econ, 1999, 5(1): 45 [25] Martin G R. A method for determining the relative permeability of concrete using gas. Mag Concr Res, 1986, 38(135): 90 doi: 10.1680/macr.1986.38.135.90 -
