基于拉力带的系列新型SST-LEJ设计与分析

邱丽芳 吴友炜 冷迎春 王晶琳

邱丽芳, 吴友炜, 冷迎春, 王晶琳. 基于拉力带的系列新型SST-LEJ设计与分析[J]. 工程科学学报, 2018, 40(10): 1267-1274. doi: 10.13374/j.issn2095-9389.2018.10.015
引用本文: 邱丽芳, 吴友炜, 冷迎春, 王晶琳. 基于拉力带的系列新型SST-LEJ设计与分析[J]. 工程科学学报, 2018, 40(10): 1267-1274. doi: 10.13374/j.issn2095-9389.2018.10.015
QIU Li-fang, WU You-wei, LENG Ying-chun, WANG Jing-lin. Design and analysis of a series of new SST-LEJ based on tension straps[J]. Chinese Journal of Engineering, 2018, 40(10): 1267-1274. doi: 10.13374/j.issn2095-9389.2018.10.015
Citation: QIU Li-fang, WU You-wei, LENG Ying-chun, WANG Jing-lin. Design and analysis of a series of new SST-LEJ based on tension straps[J]. Chinese Journal of Engineering, 2018, 40(10): 1267-1274. doi: 10.13374/j.issn2095-9389.2018.10.015

基于拉力带的系列新型SST-LEJ设计与分析

doi: 10.13374/j.issn2095-9389.2018.10.015
基金项目:

国家自然科学基金资助项目(51475037)

详细信息
  • 中图分类号: TH122

Design and analysis of a series of new SST-LEJ based on tension straps

  • 摘要: 设计了一种基于大柔度的柔性铰链,命名为SS-LEJ,利用等效法推导了其弯曲等效刚度的理论计算公式,通过设计实例的理论计算和ABAQUS仿真分析,验证理论计算公式的正确性.为了有效提升SS-LEJ的抗拉压性能,设计了4种不同位置和形状的拉力带的SST-LEJ,通过弯曲性能和抗拉压性能的有限元仿真分析,得出SST3-LEJ和SST4-LEJ为4种SST-LEJ当中整体性能较优的两种.将SST3-LEJ和SST4-LEJ与SS-LEJ、Inverted Bending-Orthogonal铰链进行了弯曲性能和抗拉压性能的比较,得出SST3-LEJ和SST4-LEJ的弯曲性能介于SS-LEJ和Inverted Bending-Orthogonal铰链之间,抗拉压性能优于SS-LEJ和Inverted Bending-Orthogonal铰链,说明SST3-LEJ和SST4-LEJ的整体性能较好,达到了预期的设计目的,为大柔度柔性铰链的设计提供了一种思路.
  • [1] Uicker J J, Pennock G R, Shigley J E. Theory of Machines and Mechanisms. 4th Ed. Oxford:Oxford University Press, 2011
    [2] Howell L L. Compliant Mechanisms. New York:John Wiley&Sons Inc, 2001
    [3] Smith S T. Flexures:Elements of Elastic Mechanisms. CRC Press, 2000
    [4] Lobontiu N. Compliant Mechanisms:Design of Flexure Hinges. CRC Press, 2003
    [5] Jacobsen J O, Howell L L, Magleby S P. Components for the design of lamina emergent mechanisms//ASME 2007 International Mechanical Engineering Congress and Exposition. Seattle, 2007:165
    [6] Jacobsen J O, Winder B G, Howell L L, et al. Lamina emergent mechanisms and their basic elements. J Mechanisms Robotics, 2010, 2(1):01003
    [7] Zirbel S A, Trease B P, Magleby S P, et al. Deployment methods for an origami-inspired rigid-foldable array//Proceedings of the 42nd Aerospace Mechanisms Symposium. NASA Goddard Space Flight Center, 2014:189
    [8] Aten Q T, Jensen B D, Burnett S H, et al. A self-reconfiguring metamorphic nanoinjector for injection into mouse zygotes. J Rev Sci Instrum, 2014, 85(5):055005-1
    [16] Wilding S E, Howell L L, Magleby S P. Spherical lamina emergent mechanisms. Mechanism Machine Theory, 2012, 49:187
    [17] Jacobsen J O, Chen G M, Howell L L, et al. Lamina emergent torsional (LET) joint. Mechanism Machine Theory, 2009, 44(11):2098
    [18] Aten Q T, Jensen B D, Howell L L. Geometrically non-linear analysis of thin-film compliant MEMS via shell and solid elements. Finite Elem Anal Des, 2012, 49(1):70
    [21] Delimont I L, Magleby S P, Howell L L. A family of dual-segment compliant joints suitable for use as surrogate folds. J Mech Des, 2015, 137(9):092302
    [23] Chen G M, Howell L L. Two general solutions of torsional compliance for variable rectangular cross-section joints in compliant mechanisms. Precis Eng, 2009, 33(3):268
  • 加载中
计量
  • 文章访问数:  406
  • HTML全文浏览量:  69
  • PDF下载量:  5
  • 被引次数: 0
出版历程
  • 收稿日期:  2017-09-15
